PTL-UMB is a CE Certified Millimeter Grade Desktop Programmable Dip Coater (1µm/s-500µm/s). The system is controlled by SBC, which provides adjustable dipping speed, pulling speed, and travelling length. It is designed for R&D Lab to prepare various optical or epitaxial films from liquid solution.
| Working Voltage | 110/220V AC selectable |
| Travelling Distance | 0-60 mm Adjustable |
| Dipping/Pulling Speed | 1µm/s-500µm/s, controlled by digotal pannel. |
| Sample Holder | Two screw sample clips are installed in the sample holder in order to carry the samples sliding up and down through two guide rods |
| Beaker Holder | The beaker which contains the coating material (coating solution) will be placed into the slot of the beaker holder. |
| Max. Sample Size | 75mm*25mm*2.5mm |
| Sample Weight | Less than 250g |
| Dipping/Pulling Motor | Stepping Motor |
| Oven |
|
| Product Dimensions | 460mm(L) x 510mm(W) x 970mm(H) |
